ARC120mini/ARC140mini/ARC160mini
1. IGBT Inverter tech, small, light, portable.
2. MCU Smart control -High consistency of stable performance.
3.Wide working input range 155-265V(1ph) 50/60HZ
4. Friendly work on generator.
5. Solder up to 3.2mm(1/8) or 4.0mm(5/32) electrodes.
6. Hot start: amazing easy arc strike once touch the workpiece
7.Anti-stick electrodes- Easy the electrode removal from workpiece.
8. Arc Force Integrated: Provide smoother welding and deeperpenetration.
9.Available to work on the Min 0.8mm workpiece.
10.Allows solder in E7018,E6010,E6011,E6013,E308 and generally all type electrodes.
11. Automatic protection against over load, over heat, ower or toolow voltage and short circuit.
12. Lift Tig integrated-TIG welding can also be performed.
13. Suitable for small scale construction work, upholster
industry,highly altitude, field operation, repairing and the homehandyman.
Model | Input voltage | No-load voltage | Efficiency | Input Power | Output Current | Duty Cycle | Welding
Rod | Weight | Dimensions(cm) |
ARC120mini | 230V土10% 50/60hz(1ph) | 75V | 85% | 5.5KVA | 30-120A | 60% | 1.5-3.2mm（1/8") | 2.5kgs | 22*9*15 |
ARC140mini | 230V土10% 50/60hz(1ph) | 75V | 85% | 6.1KVA | 30-140A | 60% | 1.5-3.2mm（1/8") | 2.8kgs | 22*9*15 |
ARC160mini | 230V土10% 50/60hz(1ph) | 75V | 85% | 6.9KVA | 30-160A | 60% | 1.5-4.0mm（5/32") | 3.2kgs | 22*9*15 |
